150 EXTREME™ Cat 6 QUICKPORT™ Jacks, Bulk QUICKPACK™, Light Almond, Kitted with JackRapid™ Tool

150 EXTREME™ Cat 6 QUICKPORT™ Jacks – Category 6 Connectivity

The 150 EXTREME™ Cat 6 QUICKPORT™ Jacks are designed for reliable Category 6 UTP connectivity and compatibility with all QUICKPORT compatible products. These jacks incorporate patented Retention Force Technology™ to ensure consistent performance and system longevity. Featuring a 180-degree rear termination configuration with unique pair separation towers, they enable quicker, easier terminations suitable for voice, data, and network applications. Ideal for electrical distributors and lighting solutions providers requiring high-performance wire and cable connectivity components.

Specifications

• Manufacturer Part #: 61110-JT6
• Color: Almond
• Product Weight: 3.6250 lbs
• Country of Origin: United States
• Made in USA: Yes
• Compliance Standards: ANSI/TIA-568.2-D (Cat 6), ISO/IEC 11801-1 (Class E), EN 50173-1 (Class E), ANSI/TIA-1096-A, c(UL)us Listed (UL 1863), UL 2043 Plenum Certified, IEEE 802.3bt PoE Type 1-4 (100 watts max)
• Material: High-impact, fire-retardant plastic rated UL 94V-0; copper-based alloy spring-wire contacts plated with 50 microinches gold over 100 microinches nickel
• Dimensions: 16.1 mm (height), 14.6 mm (width), 30.6 mm (depth)
• Operating Temperature: -10 ºC to +60 ºC (+14 ºF to +140 ºF)
• Storage Temperature: -40 ºC to +70 ºC (-40 ºF to +158 ºF)
• Humidity: 95% relative humidity, non-condensing

Features

• Patented Retention Force Technology™ protects contact tines and enhances system longevity
• Unique pair separation towers minimize untwisting and facilitate quicker terminations
• 180-degree rear termination configuration with punch field in the back for easy access
• Terminates 26 to 22 AWG solid conductors and 24 to 22 AWG stranded conductors
• Capable of multiple re-terminations with gas-tight IDC jacks to prevent corrosion
• Dual-layer T568B/T568A wiring label simplifies punchdown and supports universal wiring schemes
• Snap-in style jack with high pullout force dust cap for secure connection and protection
• Available in 13 ANSI/TIA-606-C compatible colors for color coding and organization
• Offered individually, in bulk packages of 25, and bulk packages of 150 with JACKRAPID™ Punchdown Tool
• Select colors available in Sustainably Smart Packaging that is fully recyclable and plastic-free
