3M Fire Barrier Moldable Putty Stix MP+, 1.4 in x 11 in, 10/case

3M Fire Barrier Moldable Putty Stix MP+ – Firestop Putty

3M Fire Barrier Moldable Putty Stix MP+ is a one-part, intumescent fire-resistive putty designed to restore the integrity of fire-rated building construction. It is used primarily in through-penetration firestop applications including cable bundles, insulated pipe, electrical conduit, and metal pipe penetrations. This product is suitable for electrical distributors and lighting solutions providers requiring reliable firestop materials that prevent the spread of fire, smoke, and toxic gases while maintaining compliance with building codes.

Specifications

• Color: Red-Brown
• Dimensions: 1.4 in diameter x 11 in length
• Weight: 10.5650 lbs (per case of 10 Stix)
• Fire Resistance: Up to 4 hours (system dependent, tested to ASTM E814/UL 1479)
• Adhesion: Good to all common building substrates including metal electrical boxes
• Heat Expansion Begins: 225¬∞F (107¬∞C)
• Significant Heat Expansion: 350¬∞F (177¬∞C)
• Free Expansion: Nominally 3 times original volume
• Halogen-Free: Yes, non-corrosive and safe for sensitive electrical equipment
• VOC: Low, with minimal odor
• Compliance: Meets NEC 300-21 (NFPA 70), SBCCI, BOCA, ICBO Building codes

Features

• Hand-moldable, no special tools or damming required for easy application
• Remains pliable and flexible throughout installation; will not dry out or crumble
• Provides immediate draft and cold smoke seal (L-Rating) after installation
• Intumescent formula expands under heat to form a hard char that blocks fire and hot gases
• Halogen-free, solvent-free, and asbestos-free formulation reduces risks to occupants and equipment
• Easily re-enterable for retrofit and maintenance applications
• Red color widely recognized as a firestop material for easy identification
• Helps reduce sound transmission in fire-rated wall assemblies
