7-Day Heavy-Duty Programmable Timer, 120-277 VAC, 15A, Light Almond

7-Day Heavy-Duty Programmable Timer, 120-277 VAC, 15A, Light Almond

This 7-Day Heavy-Duty Programmable Timer from Intermatic offers versatile scheduling capabilities for a wide range of electrical applications. Designed for use by electrical distributors and lighting solutions providers, it supports incandescent, fluorescent, CFL, and LED loads without requiring a neutral wire connection. Suitable for medium-duty loads such as lights, fans, and pumps, it features a programmable 7-day schedule with up to 40 ON/OFF events. The timer is compatible with single-pole and 3-way switch installations, making it a flexible choice for wire and cable setups and switchgear suppliers.

Specifications

• Operating Voltage: 120-277 VAC, 50/60 Hz
• Load Rating: 15 A Resistive (heater), 15 A Tungsten (incandescent) at 120 VAC, 6 A at 208-277 VAC
• Ballast (fluorescent): 8 A at 120 VAC, 4 A at 208-277 VAC
• Motor Load: 1 HP at 120 VAC, 2 HP at 240 VAC
• DC Loads: 4 A at 12 VDC, 2 A at 28 VDC
• Dimensions: 4.125 in (Height) x 1.812 in (Depth)
• Operating Temperature Range: 32°F to 104°F
• Battery: Replaceable CR2 lithium battery
• Country of Origin: Thailand
• Manufacturer Part Number: ST01A

Features

• 7-day programmable schedules with up to 40 ON/OFF events
• No neutral wire required for installation, enabling easy retrofit
• Compatible with incandescent, fluorescent, CFL, and LED lighting
• Astronomic feature automatically adjusts to sunrise and sunset times
• Automatic Daylight Saving Time (DST) adjustment
• Random setting turns lights ON and OFF at slightly different times each day to enhance security
• Single or 3-way switch compatible for flexible wiring configurations
• Schedules and settings stored indefinitely in non-volatile memory
• Battery-powered for maintaining time and date during power interruptions
• Suitable for medium-duty electrical loads including lighting, fans, and pumps
