AC/DC True RMS Clamp Meter, 600V, 600A

AC/DC True RMS Clamp Meter, 600V, 600A – Electrical Testing Equipment

The Greenlee AC/DC True RMS Clamp Meter, model CM-960, is a handheld electrical testing instrument designed for accurate measurement of AC and DC currents up to 600A and voltages up to 600V. It is engineered for professional electricians and electrical distributors requiring precise diagnostics in wire and cable systems, lighting solutions, and switchgear applications. This clamp meter supports true RMS readings for both AC and AC+DC signals, ensuring reliable measurement across complex waveforms commonly found in industrial and commercial electrical environments.

Specifications

• Amperage Measurement: 60.00A, 600.0A
• Voltage Measurement: 600V
• Display: LCD, 6000 Count
• Frequency Rating: Voltage AmpTip‚Ñ¢ Current 50/60Hz; High Current 50 to 400Hz
• Resistance: 600.0Œ©, 6.000kŒ©, 60.00kŒ©
• Capacitance: 200.0¬µF, 2500¬µF
• Jaw Opening: 1.18" (30 mm)
• Measurement Category: CAT III 600V, CAT IV 300V
• Product Weight: 1.34 lbs
• Country of Origin: Taiwan
• Manufacturer: Greenlee
• Manufacturer Part #: CM-960

Features

• True RMS measurement of AC and DC current for accurate readings on non-linear loads
• AC and AC+DC voltage measurements with digital low pass filter for precision on variable frequency drives
• Measures DC voltage, resistance, capacitance, and frequency
• Continuity and diode testing capability
• Peak-RMS function to capture motor inrush current
• Backlit LCD and relative zero mode for enhanced usability in low light and complex measurement scenarios
• AmpTip‚Ñ¢ technology enhances accuracy on small wires and low current measurements
• Two voltage detection modes: non-contact electric field detection and single test lead voltage detection
• Data hold and recording of maximum, minimum, and average readings for analysis
• Automatic ranging and intelligent auto power-off to conserve battery life
