ALED4T150SF

ALED4T150SF LED Area Light - High-Efficiency Lighting Solution

The ALED4T150SF is a high-performance LED area light designed for commercial and industrial lighting applications. Engineered for electrical distributors and lighting solutions providers, this fixture delivers efficient, reliable illumination with a Type IV distribution pattern ideal for mounting on building sides, walls, and parking lot perimeters. The robust die-cast aluminum housing with tempered glass lens ensures durability and suitability for wet locations, making it a dependable choice for wire and cable and switchgear suppliers requiring quality outdoor lighting components.

Specifications

• Product Weight: 32.9 lbs
• Input Wattage: 156 watts
• LED Wattage: 150 watts
• Lumens: 18,464 lumens
• Efficacy: 118.5 lumens per watt
• Color Temperature: 5000 kelvins (Cool)
• Color Accuracy: 71 CRI
• L70 Lifespan: 100,000 hours
• Ambient Temperature Rating: 104¬∞F (40¬∞C)
• Minimum Starting Temperature: -40¬∞C (-40¬∞F)
• Lens Material: Tempered Glass
• Housing Material: Die-cast aluminum housing, lens frame, and mounting arm
• Mounting: Heavy-duty mounting arm with O-ring seal and stainless steel screws
• Ingress Protection: IP66 rated for dust and water
• IES Classification: Type IV (Forward Throw) distribution
• Driver Type: Constant Current, Class 2, 2100mA, 100-277V, 50-60Hz
• Power Factor: 99.5% at 120V, 93.7% at 277V
• Surge Protection: 4kV
• Certifications: UL Listed, DLC Qualified (DLC Product Code: P0000175F)

Features

• 66% energy cost savings compared to 400W Metal Halide equivalents
• 100,000-hour LED lifespan supported by LM-80 and TM-21 testing
• Superior thermal management with external Air-Flow fins
• Specular vacuum-metallized polycarbonate reflector for optimized light distribution
• High durability finish formulated for long-lasting color retention
• 7-step MacAdam Ellipse binning for consistent color uniformity and stability
• Suitable for use in wet locations with IP66 rating
• Compliant with Buy American Act upon request
• 5-year no-compromise warranty covering light output, color stability, driver performance, and fixture finish

Downloads & Links

• Instructions
• Spec Sheet
