APPLETON AJBEW242408 JUNCTION BOX APPLETON TAG#88A

APPLETON AJBEW242408 Junction Box Explosionproof Enclosure

The APPLETON AJBEW242408 is an explosionproof junction box designed for hazardous environments where electrical safety is critical. It is suitable for use by electrical distributors, lighting solutions providers, wire and cable installers, and switchgear suppliers requiring reliable enclosures for terminals, splicing wires, pull boxes, and bus boxes. This enclosure meets NEC/CEC safety standards for Class I, Division 1 and 2, Groups B, C, D; Class II, Division 1 and 2, Groups E, F, G; and Class III hazardous locations, providing dust-ignitionproof and explosionproof protection with NEMA 4, 7, and 9 ratings.

Specifications

• Manufacturer: Appleton Electric
• Manufacturer Part #: AJBEW242408
• Product Weight: 269.5 kg
• UL Standard: UL 1203
• cULus Listed: E85310
• CSA Standards: C22.2 No. 25, C22.2 No. 30
• CSA Certified: 042129
• Overall Dimensions (mm): 746.3 (F) x 746.3 (E) x 363.5 (A)
• Mounting Dimensions (mm): 466.9 (AA) x 622.3 (BB)
• Inside Dimensions (mm): 622.3 (W) x 247.7 (H) x 38.1 (Db)
• Max Conduit Size: 4 inches
• Ship Weight: 102.1 kg (225 lb)
• Mounting Hardware: 4 bolts

Features

• Precision machined flame path between box and cover for explosionproof integrity
• Bolt-on stainless steel slotted mounting feet for flexible horizontal or vertical mounting
• Flexible hinge mounting on left or right side standard on boxes 12 x 12 x 6 inches and larger
• External flange design maximizes internal space
• Wall thickness supports a minimum of five full threads for secure assembly
• Provision for mounting pan included
• Wide range of drilled and tapped conduit outlets available
• Ground lug package and installation instructions included for proper grounding
• O-ring neoprene gasket ensures watertight integrity
• Standard materials include sand cast copper-free aluminum body and cover, stainless steel cover bolts and hinges, and galvanized steel mounting pan
• Shot blast finish standard for bodies and covers
