APPLETON ARC3044BC 30A CONN BODY ASSY 4W-4P S1

APPLETON ARC3044BC 30A Connection Body Assembly - Electrical Connector

The APPLETON ARC3044BC is a 30 Amp, 4-wire, 4-pole connection body assembly designed for use in industrial electrical distribution systems. It serves as a reliable component in wire and cable connections for portable or fixed electrical equipment, suitable for applications requiring robust and watertight connectors. This product is ideal for electrical distributors and switchgear suppliers looking for durable lighting solutions and power distribution components compliant with NEC/CEC standards for ordinary (unclassified) locations.

Specifications

• Manufacturer: Appleton Electric
• Manufacturer Part #: ARC3044BC
• Current Rating: 30 Amps
• Number of Poles: 4
• Number of Wires: 4
• Voltage Rating: 600 VAC, 250 VDC maximum
• Frequency: 50-400 Hz
• Wire Size Range: #10 to #6 Building Wire, #10 to #8 Extra Flex
• Wire Recess Diameter: 0.281 inches
• Cable Diameter Range: 0.500 to 1.125 inches
• Product Weight: 1.75 lbs
• UPC: 781381440585
• NEC/CEC Listed for Ordinary (Unclassified) Locations
• NEMA Ratings: 3, 4, 4X

Features

• Copper-free aluminum housing for rugged and corrosion-resistant construction
• Pin and sleeve design with energized contacts deeply recessed to reduce accidental touching and exposure to arcs
• Neoprene bushing seals out water and dust, providing watertight protection when mated with a plug and clamping ring
• Pressure wire terminals with spring contacts ensure firm conductor grip and allow easy cable replacement
• Plug mechanical cable clamps provide strain relief for conductor connections
• Two grounding styles available; Style 1 grounds through shell only
• Compatible with Powertite plugs and connectors for secure, watertight unions
• Positive polarization and self-aligning floating plug and receptacle contacts to prevent mismatching
• Designed for use with copper conductors only
