APPLETON EDS2190 2-UNIV P.B. 1-G 3/4 STA. FS

APPLETON EDS2190 2-UNIV P.B. 1-G 3/4 STA. FS Explosionproof Control Station

The Appleton EDS2190 is a factory sealed, explosionproof, dust-ignitionproof control station designed for heavy-duty electrical applications. It is intended for use in hazardous locations such as chemical plants, petrochemical plants, refineries, and other process industries where flammable vapors, gases, or combustible dusts are present. This control station is ideal for remote motor control and circuit selection, providing reliable push button operation and pilot light indication with robust construction suited for industrial environments. It is suitable for electrical distributors, lighting solutions providers, wire and cable specialists, and switchgear suppliers requiring certified hazardous location equipment.

Specifications

• Manufacturer: Appleton Electric
• Manufacturer Part Number: EDS2190
• Product Weight: 10.23 lbs
• Electrical Rating: 10 Amp, 600 Vac max, Heavy Duty
• Hub Size: 3/4 inch
• Classification: NEC/CEC Class I, Division 1 & 2, Groups C, D; Class II, Division 1 & 2, Groups E, F, G; Class III
• NEMA Rating: 3, 7CD, 9EFG
• UL Standards: UL 508, UL 698, UL 1203
• CSA Standards: C22.2 No. 14
• cULus Listed: E10449, E81751
• Material: Malleable iron body and cover
• Finish: Epoxy powder coat over zinc electroplate and chromate for corrosion resistance

Features

• Factory sealed enclosure eliminates the need for sealing fittings and compound at conduit entrances
• Internal ground screw installed for ground continuity
• Corrosion-resistant stainless steel hex head captive screws secure covers to body
• Large backbox provides ample wiring room
• Push button and selector switch contacts use silver cadmium oxide sealed in phenolic chamber for long-term reliability
• Stainless steel push button shaft and bushing ensure maintenance-free operation
• Heavy duty 10 Amp, 600 Vac rating suitable for industrial control circuits
• Dozens of possible combinations with push buttons, pilot lights, and selector switches
• Factory sealed pilot lights supplied with jewel/guard assembly and 120 Vac/Vdc, 50/60 Hz, 6 Watt lamp (LED options available)
• All momentary push buttons supplied with lockout type guards to prevent unauthorized operation
• Clearly marked terminals with brass screws and spade terminals for quick, easy wiring
