APPLETON ENR5201 U-LINE RCPT ASSY 20A 125V

APPLETON ENR5201 U-LINE RCPT ASSY 20A 125V - Explosionproof Receptacle

The APPLETON ENR5201 U-Line Receptacle Assembly is a factory-sealed, explosionproof and dust-ignitionproof electrical receptacle designed for hazardous locations. It is suitable for use where portable electric equipment requires power in environments with flammable vapors, gases, or corrosive conditions. This product is ideal for electrical distributors and switchgear suppliers serving industrial applications such as lighting solutions, conveyors, heaters, motor-generator sets, air conditioners, compressors, and pumps. The receptacle is UL Listed and UL Classified for use in Class I, Division 1 and 2, Groups C, D, and B, Class II, Division 1 and 2, Groups F, G, and Class III hazardous locations.

Specifications

• Manufacturer: Appleton Electric
• Manufacturer Part Number: ENR5201
• Voltage Rating: 125 VAC
• Current Rating: 20 Amperes
• UL Listings: UL 1203, UL 1010, UL 894, UL Listed E10784
• Type: Factory Sealed Receptacle
• Construction: Malleable iron mounting box with triple-coat finish (zinc electroplate, chromate, epoxy powder coat)
• Receptacle Cover Material: Copperfree aluminum (4/10 of 1% max.) with epoxy powder coat finish
• Ingress Protection: NEMA 3RX when spring-loaded cover is installed and closed; NEMA 4X when screw cover kit is installed and fully engaged
• Dimensions: See detailed dimensional drawings on page 4 of installation manual
• Product Weight: 1.89 lbs

Features

• Explosionproof and dust-ignitionproof design suitable for hazardous locations
• Dead-front receptacle design ensures no energized contacts until plug is fully inserted and switched
• Spring-loaded cover with neoprene gasket seals receptacle from dirt, water, dust, and corrosive atmospheres
• Factory sealed interior with integral switch housed in aluminum sleeve with protective xylan coating for smooth operation
• ECP Interchanger plug compatibility with standard non-explosionproof receptacles and U-Line explosionproof receptacles
• Solderless pressure-type terminal lugs for ease of wiring
• Longer plug housing for better grip and easier insertion/withdrawal
• Plug mechanical cable clamps meet or exceed UL 150 lb. strain relief pull-out test for classified locations
• Optional aluminum mounting boxes available with suffix ‚ÄìSA
