APPLETON JBR6034150 SWITCHED RECPT. 60A 3W4P

APPLETON JBR6034150 SWITCHED RECPT. 60A 3W4P Electrical Distributor Switchgear

The APPLETON JBR6034150 is a 60 Amp, 3-wire, 4-pole switched receptacle designed for use in hazardous locations requiring robust and weatherproof electrical connections. Manufactured by Appleton Electric, this interlocked receptacle provides safe power distribution for portable or fixed electrical equipment such as motor-generator sets, pumps, compressors, and lighting systems. It is suitable for applications in harsh environments including shipping docks and industrial sites, meeting stringent NEC and UL standards for hazardous locations.

Specifications

• Manufacturer Part #: JBR6034150
• Amperage: 60 Amperes
• Poles/Wires: 3W, 4P (3-wire, 4-pole)
• Voltage Rating: 600 VAC, 50-400 Hz
• Conduit Entry: 1-1/2" vertical feed-thru with reducer bushings to 1-1/4"
• Material: Copper-free aluminum housing (max 0.4% copper)
• Finish: Epoxy powder coat
• Mounting: (4) 3/8" steel hex-head bolts (not supplied)
• UL Standards: UL 1010, UL 894, UL 1682
• UL Listed: E10784
• Compatible Mating Plugs: ACP6034BC and CPH6034BC (UL Listed ACP plugs; CPH plugs with -BC suffix not UL listed)
• Maximum Motor Horsepower: 30 HP at 600 VAC for 3-phase, 3W, 4P
• Product Weight: 23.05 lbs

Features

• Dead front interlocked construction with internal disconnect switch for safe and quick disconnection without separate switch
• Plug must be fully inserted before switch can be turned on, ensuring safe engagement
• Positive polarization prevents mismating with plugs of different style, poles, or amperage
• Receptacle supplied with both flip cover and screw cover for environmental protection; flip cover suitable for NEMA 3, 3R; screw cover enables NEMA 4, 4X rating
• Terminal block factory wired to receptacle for ease of wiring and maintenance
• Style 2 grounding through shell and extra pole with grounding terminal provided
• Receptacle can be locked in the "OFF" position for safety lockout/tagout procedures
• O-ring gasket between mounting box and receptacle cover for weatherproof sealing
• Mounting box includes vertical feed-thru conduit openings with NPT threads and reducer bushings for 1-1/4" conduit
• UL classified for use with competitor plugs such as Crouse-Hinds APJ series
• Rugged, weatherproof construction suitable for hazardous locations including Class I, Division 1 and 2, Groups B, C, D; Class II, Division 1 and 2, Groups F, G; Class III
