APPLETON N2LED2T1 N2LED, MASTER UNIT TWO LAMP HEADS, TOP ENTRY

APPLETON N2LED2T1 Master Unit Two Lamp Heads Emergency Lighting System

The APPLETON N2LED2T1 is a non-metallic emergency lighting master unit designed for hazardous locations, providing reliable egress lighting with two integrated LED lamp heads and top entry conduit hub. This system is ideal for electrical distributors and lighting solutions providers serving industrial and hazardous environments such as manufacturing plants, refineries, petrochemical facilities, and other corrosive or wet locations. It supports both main and remote light heads, offering flexible configurations for emergency lighting in compliance with NEC and CEC standards.

Specifications

• Manufacturer: Appleton Electric
• Model Number: N2LED2T1
• Number of LED Lamps: 2
• Total Watts of LED Lamps: 3 Watts
• Input Voltage: 120-277 Vac
• Frequency: 50/60 Hz
• Hub Size: 3/4" NPT
• Entry Location: Top Entry
• Weight: 3.27 kg (7.2 lb)
• Battery Type: Maintenance-free NiCd battery
• Operating Temperature Range: 0 ¬∞C to +55 ¬∞C (+32 ¬∞F to +131 ¬∞F)
• Enclosure Rating: NEMA Type 4X, IP66, Marine Outside Type (Salt Water)
• NEC/CEC Certification: Class I, Division 2, Groups A, B, C, D; Class I, Zone 2, Group IIC
• UL Standards: UL 1598A, UL 924, UL 844
• CSA Standards: C22.2 No. 141-M1985, C22.2 No. 137-M1981
• cCSAus Certified: 2715744
• Warranty: 5 years standard

Features

• Enclosed, gasketed, and raintight fiberglass reinforced polyester housing for use in highly corrosive and wet locations
• Supports up to 4 light heads with a maximum output power of 6 watts (two heads factory installed)
• Integrated illuminated push-to-test switch for system status and error code indication
• Solid-state charger with transfer circuit and low voltage battery disconnect to protect the battery from deep discharge
• Universal input circuit supporting 120-277 Vac, 50/60 Hz power supply
• Provides 100% lumen output for 90 minutes with four light heads or 180 minutes with two light heads
• Automatic periodic self-test every 30 days with user-initiated push-to-test function
• Remote lamp head assemblies available for mounting away from the main unit
• Nickel-plated brass conduit hub with ground lug for secure wiring connections
• Maintenance-free sealed NiCd battery suitable for harsh temperature environments
• Marine wet location suitability and compliance with Life Safety Code NFPA101¬Æ Section 5-9 for emergency lighting
